High End Systems FULL BOAR 4 Console

High End Systems’ Full Boar 4 is versatile enough to handle everything from a corporate show to a full stadium gig. The Full Boar 4 offers all the power of the flagship Hog 4, but in a more compact and affordable package, with sleek lines, raked screens, and that familiar layout.

Full Boar 4 provides two 15.6-inch multi-touch monitors and two additional video outputs. Four on-board DMX universes drive the rig, and two gigabit Ethernet ports are provided for Art-Net, sACN, and console networking. Full Boar 4 satisfies the demanding programmer, and brings the package in on budget.

FEATURES

• Robust Hog 4 OS operating system
• Hog-Net etherCON connector
• Fixture-Net etherCON connector
• Unlimited simultaneous crossfades
• Internal solid-state hard drive
• Two internal 15.6-inch 10-point touchscreens
• Up to two external DVI-I monitors/touchscreens supported
• 10 motorized playback faders
• Motorized Grand Master
• Dedicated DBO toggle key
• Five expanded-wheelset encoders
• 12 user-assignable function keys with associated LCD
• Tri-axis backlit trackball with rotary encoder and four configurable buttons
• Kensington security slot
• Integrated dimmable white lap work light
• Integrated dimmable blue vent light
• Two dimmable white/blue desk lights included
• Two USB flash drives for show storage and console recovery included
• Dust cover included
• Custom road case included

CONNECTIVITY

• Local output processing: 12x universes (6144 output channels)
• Local DMX-512 outputs: 4x Neutrik 5-pin XLR
• Expandable DMX-512 outputs via USB DMX Widgets
• Local Art-Net and E1.31/sACN outputs: 1x 1GB/s Ethernet port
• Unlimited DMX-512, Art-Net and E1.31/sACN universes via HogNet-connected DP8Ks
• LTC/SMPTE input via 3-pin XLR
• MIDI in/out/thru supporting MIDI messages, MIDI Show Control, and MIDI Time Code
• Expandable MIDI and LTC inputs via USB MIDI/LTC Widgets
• Connectivity with visualizers via Fixture-Net (Art-Net or E1.31/sACN, unrestricted by local output capacity)
• OSC (Open Sound Control) for remote control and integration
• Supports USB playback and expansion Wings
• USB 2.0 ports: 4 rear
• USB 3.0 ports: 1 top

ELECTRICAL

• Compliance: ETL, CETL, CE
• Mains power: 100-250VAC, 50/60Hz, max 110W
• Mains connector:  IEC320 C13
• Fuse: 1x 5x20mm 5AT fuse

WEIGHTS AND DIMENSIONS

• Width: 902mm / 35.5"
• Depth: 610mm / 24.0"
• Height: 244mm / 9.6"
• Weight: 20.4kg / 45lb

OPTIONAL ACCESSORIES

• FULLBOAR4DC - Full Boar 4 console dust cover (replacement)
